NMAxe / NMAxe Gamma Accessories
NMAxe / NMAxe Gamma Accessories Use the BM1370 ASIC Chip the Hashrate Increased From 500GH/s( NMAxe) to 1.2 TH/s
Product introduction
NMAxe use the BM1366 ASIC chip, hashrate 500GH/s. NMAxe gamma is based on Bitaxe-gamma (bitaxe-601) project, use the BM1370 ASIC chip, it’s an open-source project specialized for solo miner, the hashrate increased from 500GH/s( NMAxe) to 1.2 TH/s.
Summary
NMAxe-Gamma is an NMMiner Offical development board, with BM1370 ASIC, Wi-Fi, and Bluetooth solo lottery Miner. Perfect for solo miners aiming to hit a Bitcoin block, the NMAxe-Gamma is your golden ticket to potentially earning the 3.125 Bitcoin block reward. The NMAxe-Gamma increased the hashrate to 1.2TH/s, 2.4 times of NMAxe’s 500GH/s. More high-efficiency, rewarding experience makes it the ultimate lottery miner on the market.
Goals
- Standalone: You can mine directly to the pools over WiFi. No External computer is needed.
- Embedded: low cost, low maintenance, high availability, high reliability, low power( about 20W). Same power consumption with the NMAxe, but more energy-efficient.
- ASIC: based on the very, very efficient BM1370 from Bitmain.
BM1370
- The BM1370 is an undocumented SHA256d mining ASIC from Bitmain.
- It’s used in the Antminer S21.
- Bitmain claims the BM1370 has 16J/TH efficiency.
The software ESP-Miner-NMAxe is fully open-source.
It’s from the open-source project:
Specification
- Tab1
|
Origin
|
Mainland China
|
|
Integrated Feature
|
WiFi 802.11b/g/n, BLE
|
|
Device management
|
Web service Axe OS/NMController
|
|
Master Chip
|
ESP32-S3FN8, Xtensa32 dual core processor
|
|
ASIC
|
BM1370
|
|
HashRate
|
1000 ~ 1300 GH/s
|
|
Wi-Fi
|
802.11 b/g/n, up to 150Mbps
|
|
Power supply range
|
12V /3A
|
|
Display
|
1.14 inch TFT-LCD display 135*240, 262k colors
|
|
Supply mode
|
DC adapter and USB PD charger are supported
|
|
Memory
|
384KB ROM; 512KB SRAM; 16MB SPI Flash
|
|
Power Interface
|
Type-C USB\DC2.0
|
|
Power Consumption
|
18~30W
|
|
Operating temperature
|
-20 ~ 70 ℃
|
Picture display
