NMAxe-Gamma
NMAxe-Gamma with BM1370 ASIC and ESP32-S3, with Wi-Fi, Bluetooth smaller size, more stable performance
♦Full graphic screens over 1.14 inch IPS screen.
♦Bitmain’s BM1370 chip.
♦Operates exclusively on 2.4 GHz Wi-Fi.
♦Requires a 12V power supply with at least 3A.
♦Support normal USB-PD supply, at least 9V/4A.
♦Easy setup via the AxeOS portal.
♦NMMiner Group Controller for monitoring, Can easily manage multiple devices, both NMMiner, NMAxe/Gamma.
♦Support different Crypto cucrrency using SHA256d Solo mining, such as BTC/BCH/XEC/DGB.
♦The device is compatible with Raspberry Pi 5-size structure and can be compatible with Raspberry Pi related shell devices.
Product introduction
What’s this?
NMAxe-Gamma is an official NMMiner bitaxe board, featuring the BM1370 ASIC and ESP32-S3, along with Wi-Fi and Bluetooth capabilities. It is a deeply optimized version of the Bitaxe 601 (Gamma), boasting a smaller size and more stable performance. As a solo mining lottery miner, it is ideal for solo miners aiming to strike a Bitcoin block.
The NMAxe-Gamma is an upgraded version of the NMAxe, serving as your golden ticket to potentially earning the 3.125 BTC block reward (currently valued at over $300,000). Its high efficiency and rewarding potential make it the ultimate lottery miner on the market. For existing NMMiner owners, the NMAxe-Gamma boosts mining speed from 480 KH/s to 900~1200 GH/s, increasing the winning probability by nearly 2 million times. Compared to the NMAxe, the NMAxe-Gamma maintains similar power consumption while doubling the hashrate.
Notice:
The hashrate fluctuates around 1000 GH/s (900~1200 GH/s). Parameters should be set to a frequency of 625MHz and a Vcore of 1200 mV.
It is recommended that users do not set parameters that cause the device’s power consumption to exceed 30W, and ensure the device temperature remains below 60℃.
(Excessive temperature is not conducive to the long-term stable operation of the device.)
- Standalone: You can mine directly to the pools over WiFi. No External computer is needed.
- Embedded: low cost, low maintenance, high availability, high reliability, low power( about 20W).
Same power consumption with the NMAxe, but more energy-efficient.
-
ASIC: based on the very, very efficient BM1370 from Bitmain.
BM1370
- The BM1370 is an undocumented SHA256d mining ASIC from Bitmain.
- It’s used in the Antminer S21.
- Bitmain claims the BM1370 has 16J/TH efficiency.
Read More
Specification
- Tab1
|
Parameters
|
Description
|
|
Origin
|
Mainland China
|
|
ASIC
|
BM1370
|
|
Master Chip
|
ESP32-S3R8, Xtensa32 dual core processor
|
|
Hash Rate
|
1000 ~ 1200 GH/s
|
|
Wi-Fi
|
802.11 b/g/n, up to 150Mbps
|
|
Device management
|
Web service Axe OS/NMController
|
|
Power Interface
|
Type-C USB\DC2.0
|
|
Supply mode
|
DC\PD3.0 DC adapter and PD charger are supported
|
|
Power Supply
|
12V / 3A (recommend)
|
|
Power Consumption
|
20~36W
|
|
Display
|
1.14 inch TFT-LCD ; 135*240;Full-color
|
|
Fan
|
DC 5V/Dual bearing brushless Fan
|
|
Heat sink
|
40*40*30mm
|
|
Memory
|
512KB SRAM; 8MB PSRAM; 384KB ROM; 16MB SPI Flash
|
|
Dimensions
|
85*56*70mm
|
|
Operating temperature
|
-20 ~ 70 ℃
|
Picture display
