ESP32 Dev Backplane
ESP32 Dev Backplane Compatible with, wireless shell, HT-CT62 for CT62 and Wireless Shell
* Compatible with, wireless shell, HT-CT62.
* Only this bottom board, not include Wireless Shell nor any other modules;
* Not include Battery and antenna
* Include SH1.25 x 2 battery connecter.
* Only this bottom board, not include Wireless Shell nor any other modules;
* Not include Battery and antenna
* Include SH1.25 x 2 battery connecter.
Product introduction
What’s this?
Backplane designed for CT62 and Wireless Shell.
Main Features
The backplane is specifically designed for connecting the Wireless Shell V3 module, providing easy access to most of its pins. Additionally, it features integrated USB interface, two buttons, and a lithium battery interface to facilitate development with the Wireless Shell V3.
Specification
- Tab1
|
Parameters
|
Description
|
|
Interface
|
USB Type-C
|
|
Battery Interface
|
SH1.25 x 2
|
|
Input Voltage
|
5V
|
|
Main Board Voltage
|
3V3
|
|
Temperature
|
-40~85℃
|
|
Humidity
|
≤90% no condensation
|
|
Dimension
|
28x60mm
|
Picture display
