Equipped with a powerful built-in infrared illuminator, NVP8290 Night Vision Monocular enables clear viewing in low-light conditions and even total darkness.
NVP8290(standard) Night Vision Scope
NVP8290 handheld Infrared Thermal Imaging Night Vision for hunting 10 crosshair reticle options Detector resolution 354X288
※Most advanced uncooled sensor+passive IR thermal Imaging Tech
※3 in 1 Multi-purpose: Handheld/helmet/aim scope
※10 crosshair reticle options
※4 kinds imaging modes for different environment
※1920X1080 OLED HD display for viewing comfort
※Smooth Zoom from 1x to 8x
※50Hz High Frame Rate
※Recognition distance:up to 850m, Detection distance: up to 3500m
※IPX67 waterproof rate& Support Wifi
※Function: photo taking, video recording, audio recording, playback, electronic compass, inclination angle, elevation angle; infrared mode: black heat, white heat, blue heat, pseudo color
※3 in 1 Multi-purpose: Handheld/helmet/aim scope
※10 crosshair reticle options
※4 kinds imaging modes for different environment
※1920X1080 OLED HD display for viewing comfort
※Smooth Zoom from 1x to 8x
※50Hz High Frame Rate
※Recognition distance:up to 850m, Detection distance: up to 3500m
※IPX67 waterproof rate& Support Wifi
※Function: photo taking, video recording, audio recording, playback, electronic compass, inclination angle, elevation angle; infrared mode: black heat, white heat, blue heat, pseudo color
Product introduction
Equipped with a powerful built-in infrared illuminator, NVP8290 Night Vision Monocular enables clear viewing in low-light conditions and even total darkness.
The infrared-sensitive complementary-metal-oxide-semiconductor (CMOS) sensor provides edge-to-edge resolution and outstanding image quality, while the fully multi-coated optics increase light transmission and decrease glare for a clear, illuminated image.
With optical 1x-8x magnification and a 50mm objective lens, this compact night vision monocular lets you effectively view objects up to 300m away in night mode when the infrared illumination level is set to high.
If you love spotting wildlife or keep a watch out for intruders during the night, the designed the most efficient digital IR night vision binoculars. This night vision device is equipped with infrared lighting, suitable for use in pitch dark environment.
Specification
- Tab1
|
Product number
|
NVP8290 standard
|
|||
|
Detector pixel spacing
|
17um
|
|||
|
Detector type
|
Non-refrigerated vanadium oxide
|
|||
|
Detector resolution
|
354X288
|
|||
|
Electronic magnification,X
|
1X ~ 8X
|
|||
|
Objective lens diameter, mm
|
50
|
|||
|
lens focal length
|
F50MM
|
|||
|
lens aperture
|
F1.0
|
|||
|
Lens type
|
Infrared germanium lens
|
|||
|
Eyepiece magnification,X
|
15X
|
|||
|
Eyepiece exit distance
|
35mm
|
|||
|
Display specifications
|
0.39 inch 1920X1080
|
|||
|
Distance range, D
|
±5
|
|||
|
waterproof level
|
IPX67
|
|||
|
Detector noise equivalent temperature difference
|
< 35 mk ( @25°C, F# = 10)
|
|||
|
Thermal image frame rate
|
50
|
|||
|
Image adjustment
|
have
|
|||
|
Minimum resolvable temperature difference
|
500mk
|
|||
|
Thermal imaging mode
|
Black hot mode, white hot mode, blue hot mode, pseudo color mode
|
|||
|
Cross reticle
|
Various options
|
|||
|
Cross reticle correction
|
have
|
|||
|
Electronic compass
|
have
|
|||
|
WIFI
|
support
|
|||
|
USB data copy
|
TYPE-C
|
|||
|
TF card maximum support
|
256GB (32GB standard)
|
|||
|
Use battery
|
Standard 3200 mAh 26500 lithium battery
|
|||
|
Operating time (without IR, +20°C)
|
8 hours
|
|||
|
Operating temperature range,°C
|
-30……+60
|
|||
|
DC input
|
5V
|
|||
|
Bracket interface
|
Can be accessed
|
|||
|
Shockproof bracket
|
yes
|
|||
|
Bracket
|
Available
|
|||
|
Impact resistance G
|
1500G
|
|||
|
Ranging
|
Support optional
|
|||
|
Product size s (LxWxH), mm
|
210X75X55
|
|||
|
Product weight, g
|
about 600
|
|||
Product Description
The infrared-sensitive complementary-metal-oxide-semiconductor (CMOS) sensor provides edge-to-edge resolution and outstanding image quality, while the fully multi-coated optics increase light transmission and decrease glare for a clear, illuminated image.
With optical 1x-8x magnification and a 50mm objective lens, this compact night vision monocular lets you effectively view objects up to 300m away in night mode when the infrared illumination level is set to high.
If you love spotting wildlife or keep a watch out for intruders during the night, the designed the most efficient digital IR night vision binoculars. This night vision device is equipped with infrared lighting, suitable for use in pitch dark environment.
Picture display
