NVGB08 Night Vision Binoculars
NVGB08 Head Mounted Night Vision Rangefinder Goggles with a 3W Infrared Light and 4 Gears Manual Dimming for Hunting
●Minimum Illumination
●Recording and Photographic Resolution
●Range Measurement
●Optical and Digital Magnification
●Infrared Light Power
Product introduction
1.Performance:
Minimum Illumination: The NVGB08 has a minimum illumination of 0.0001 lux, which is quite impressive for capturing clear images in low-light conditions.
Recording and Photographic Resolution: It supports recording resolution up to 2560×1440 and photographic image resolution up to 7392×4160, ensuring high-quality visuals.
Range Measurement: The rangefinder can measure distances from 10M to 1200M, making it versatile for various outdoor activities.
Optical and Digital Magnification: With 1X optical magnification and 6X digital magnification, it provides detailed views of distant objects.
Infrared Light Power: Equipped with a 3W infrared light with 4 gears manual dimming, it enhances visibility in complete darkness.
2.Reliability:
Battery Life: The goggles come with a 21700 Lithium Battery, offering over 15 hours of operation without infrared light and over 6 hours with infrared light at the highest setting.
Waterproof Performance: The NVGB08 has an IPX56 waterproof rating, ensuring it can withstand various weather conditions.
Durability: The package includes a 1-year warranty and professional after-sale customer service, reflecting the manufacturer’s confidence in the product’s durability and reliability.
3.Additional Features:
Display and Camera: The goggles feature a 3″ LCD with 854×480 resolution and a 1/2.7″ CMOS camera, providing clear and detailed images.
Field of View: With a field of view of 38°x22°, it offers a wide viewing angle for better situational awareness.
Effective Observation Distance: The effective observation distance is 300M, which is suitable for most night-time activities.
In comparison to other night vision rangefinder goggles, the NVGB08 offers a comprehensive set of features that enhance both performance and reliability, making it a strong contender in its category.
Specification
- Tab1
Model
|
NVGB08
|
Photosensitive chip
|
1/2.7″CMOS 2 million pixels
|
Infrared fill light
|
3W,850mm, 4 levels adjustment
|
Low illumination capability
|
0.001lux
|
Range measurement range
|
10m-1200m
|
Range measurement accuracy
|
10≤L≤100m :±1m
L>100m :±(1+L*0.4%)m |
Display screen
|
3″ LCD, 854*480
|
Photo resolution
|
7392*4160
|
Video resolution
|
2560*1440
|
Objective lens
|
12MM
|
Eyepiece
|
72MM*40MM
|
Field of view angle
|
38*22
|
Optical zoom
|
1X(Fixed multiple)
|
Digital zoom
|
6X(Can be adjusted)
|
Effective visual distance during the day
|
1m-300m
|
Effective visual distance at night
|
1m-60m
|
Language
|
Multiple languages
|
Operation button
|
8
|
Interface
|
USB, TYPB-C
|
Power supply
|
Built-in 6000MAh 21700 lithium battery, can be powered directly by external power supply (power bank, 5v power supply)
|
Working time
|
6Hours (IR on)/ 15 Hours (IR off)
|
Working voltage
|
3.45V -5.8V -10~50℃: 525g 245*165*83mm IP56
|
Ambient temperature
|
-10~50℃:
|
Body weight and size
|
525g 245*165*83mm
|
Protection level
|
IP56
|
Electronic compass
|
yes
|
WIFI link
|
yes
|
Photography and video recording
|
yes
|
Playback
|
yes
|
Picture in picture (PIP)
|
yes
|
Display brightness adjustment
|
yes
|
Automatic switch
|
yes
|
Cross auxiliary line
|
yes
|
Time adjustment
|
yes
|
Night vision enhancement
|
yes
|
Support mobile phone connection
|
yes
|
Installation method (bracket/handheld/head mounted)
|
yes
|
Product Description

Minimum Illumination
Recording and Photographic Resolution
It supports recording resolution up to 2560×1440 and photographic image resolution up to 7392×4160, ensuring high-quality visuals.


Range Measurement
The rangefinder can measure distances from 10M to 1200M, making it versatile for various outdoor activities.
Infrared Light Power
Equipped with a 3W infrared light with 4 gears manual dimming, it enhances visibility in complete darkness.
